Unit：mm
9.8 Newton(N)=1 Kg=2.2 LBS
| Model No. |
1)
Stroke (A) |
2)
Stroke (A*) |
Extended
Length (B) |
3)4)
Tension Force FZ (N) |
3)5)
Compression FD (N) |
Weight (g) |
Remark |
| HD15C-198-C920-125N |
30 |
60 |
198 |
<25 |
125 |
|
|
| HD15C-198-C920-250N |
<25 |
250 |
|
|
| HD15C-198-C920-550N |
<25 |
550 |
|
|
| HD15C-288-C920-125N |
60 |
105 |
288 |
<25 |
125 |
|
|
| HD15C-288-C920-250N |
<25 |
250 |
|
|
| HD15C-288-C920-550N |
<25 |
550 |
|
|
| HD15C-398-C920-125N |
100 |
160 |
398 |
<25 |
125 |
|
|
| HD15C-398-C920-250N |
<25 |
250 |
|
|
| HD15C-398-C920-550N |
<25 |
550 |
|
|
